Industrial Curing Oven

50000.00 - 500000.00 INR/Piece

Get a Price/Quote

Product Details:

Power Source Electric
Control Mode Digital PID Controller
Heating Method Forced Air Circulation
Accuracy 1C
Heating Capacity 12 kW
Condition New
Type Industrial Curing Oven
Click to View more

Request to Call Back Send Inquiry

Product Details
Product Description

Industrial Curing Oven Price And Quantity

Price Range 50000.00 - 500000.00 INR/Piece
Minimum Order Quantity 1 , , Piece

Industrial Curing Oven Product Specifications

Material Mild Steel (Powder Coated)
Surface Finish Powder Coated
Control Mode Digital PID Controller
Power Source Electric
Dimension (L*W*H) 1200 mm x 1500 mm x 1800 mm
Voltage 415 V, 3 Phase
Heating Method Forced Air Circulation
Internal Size 1000 mm x 1200 mm x 1500 mm
External Size 1200 mm x 1500 mm x 1800 mm
Volume 1.8 m
Accuracy 1C
Temperature Range 50C to 300C
Heating Capacity 12 kW
Power 12 kW
Condition New
Type Industrial Curing Oven
Air Flow Horizontal/Uniform Airflow

Industrial Curing Oven Trade Information

Supply Ability 2 , , Piece Per Month
Delivery Time 1 Months

Product Description

For many years, we are instrumental in manufacturing, exporting and supplying a wide array of Industrial Curing Oven. Offered oven is efficiently manufactured under the direction of our skilled professionals using optimal quality raw material at our well-equipped production unit. This oven is mainly used in aerospace and automobile industries for curing a wide variety of composite material. Also, this Industrial Curing Oven is available with us in various technical specifications at industry leading rates.

Features:

Excellent performance
Low maintenance
Hassle-free functionality
Rugged design

Your oven have three concentric chambers, starting from inside they are

The main Working Chamber (the inner most chamber) with vertical & horizontal rack holder along with 3 vertical & 1 horizontal rack.
The Convection Chamber (the second chamber outside of the main working chamber). Heating elements @ 0.7KW x 9 Nos) & the convection fan is located in this chamber.
The Outer Insulation. This oven comes with unique layers Sandwich Insulation made of ceramic wool blanket & loose mineral wool fiber for better thermal insulation.

The motor (0.5hp 3ph AC) for the convection fan is located at the back of the oven.

The driving belt & the controls are located at the top of the oven

The sensor for temperature pick up is located at the near left corner of the oven top (facing the oven from operator side)

Advanced Forced Air Circulation

The oven is equipped with a forced air circulation heating method, utilizing strategically positioned fans to ensure uniform horizontal airflow. This results in even temperature distribution throughout the chamber, critical for consistent and reliable curing or heat treatment processes. The system supports diverse industrial applications where precision and uniformity are essential.

Digital PID Control and Superior Accuracy

With a digital PID controller, the oven maintains exact temperature settings across the full 50C to 300C range. The advanced control system regulates the environment with an impressive accuracy of 1C, minimizing any variation. This makes it ideal for industries where controlled heat is vital to product quality and process reproducibility.

Robust Build and Flexible Application

Constructed from powder-coated mild steel, this oven offers durability and a professional finish suitable for demanding industrial use. Its spacious 1.8 m chamber accommodates a wide range of products, while the robust materials and flexible operating parameters meet the needs of exporting, manufacturing, supplying, or trading in various sectors across India.

FAQs of Industrial Curing Oven:

Q: How does the forced air circulation system enhance the curing process in this industrial oven?

A: The forced air circulation system uses fans to move heated air horizontally and uniformly throughout the oven chamber. This method ensures consistent temperature exposure to all items inside, leading to uniform curing or heat treatment and minimizing hotspots or cold zones.

Q: What is the temperature range and control accuracy of this curing oven?

A: The oven operates within a temperature range of 50C to 300C, regulated by a digital PID controller. This system can maintain the set temperature with an accuracy of 1C, ensuring precise thermal processing for sensitive applications.

Q: When should this industrial curing oven be used in manufacturing processes?

A: This oven is suitable whenever controlled heat treatment, curing, or drying is required in industrial settingssuch as in the production of coatings, composites, electrical components, or materials that demand stringent temperature uniformity and control.

Q: Where can this oven be installed and operated effectively?

A: Designed for industrial environments, the oven is ideal for factories, workshops, and manufacturing units. Its robust construction and three-phase power requirement make it best suited for professional settings with adequate space and electrical infrastructure.

Q: What are the main benefits of using a digital PID controller in this oven?

A: A digital PID controller offers precise temperature regulation, minimizes temperature fluctuations, and provides user-friendly interface options. This leads to enhanced product quality, reduced waste, and consistent results batch after batch.

Q: How does the choice of material and surface finish aid the ovens durability?

A: The oven is built from durable mild steel with a powder-coated finish, offering protection against corrosion, scratches, and general industrial wear. This extends the lifespan of the oven and reduces maintenance needs.

Q: What typical processes and products benefit most from this industrial curing oven?

A: This oven is ideal for processes such as curing paints, drying coatings, heat-treating aerospace or automotive components, and processing electronic parts. Any application requiring uniform, controlled heating over a large internal volume will benefit from its design.
